MIL-PRF-44408C
(Application for copies should be addressed to the IEEE Service Center, 445
Hoes Lane, Piscataway, NJ 08855-1331.)
2.4 Order of precedence. In the event of a conflict between the text of this
document and the references cited herein, the text of this document takes
precedence. Nothing in this document, however, supersedes applicable laws and
regulations unless a specific exemption has been obtained.
3.
REQUIREMENTS.
3.1 First article. When specified (see 6.3), a sample shall be subjected to
first article inspection in accordance with 4.1a. A first article is defined as a
preproduction or an initial production sample consisting of one or more of each
type of completed shelters.
3.2
Physical Performance Requirements.
3.2.1 Weight and payload. The shelter weight and payload capacity of each
shelter type shall be as listed in table I. The maximum shelter weight listed
does not include the weight of the Mounting Kit and Pintle Extension and their
attaching hardware. The shelter shall be capable of accepting the payload
distribution specified in the contract or purchase order (see 6.2).
TABLE I.
Weight and Payload Capacity
Type
Maximum Shelter
Minimum Payload
Mounting Kit
Pintle Extension
Weight
Capacity
Incl. Hardware
Incl. Hardware
I
608 lbs
3300 lbs
88 lbs
50 lbs
II
650 lbs
3300 lbs
88 lbs
50 lbs
III
643 lbs
3300 lbs
88 lbs
50 lbs
3.2.2 Parts interchangeability.
3.2.2.1 Spare parts. The spare parts are listed in table II and are depicted on
interface drawing number 17-2-0035. All spare parts and related assemblies shall
be functionally and dimensionally interchangeable without modification or rework
of the part, assembly, or shelter.
TABLE II.
Spare Parts
PART
HMMWV Mounting Kit
Pintle Extension Kit
Door Assembly
Hatch Assembly (Type II)
Rear Ladder
Steps
T-bar Door Holder
3.2.2.2 Interface parts. The interface parts are listed in table III. All
interface parts and related assemblies shall be functionally and dimensionally
interchangeable, without modification or rework of the part, assembly, shelter, or
vehicle, with the reference parts listed in table III.
3
